Electronic Throttle Module (ETM) Problem 1999 Volvo V70

Posted by OurVolvo.com on Jan 25, 2012 in 1999 Volvo V70

This post deals with detecting problems in your ETM (Electronic Throttle Module) manufactured by Magneti Marelli (Fiat) for Volvo between 1999 and 2001.

A few years back, VOLVO denied the problem and did NOT recall the part, but extended the warranty to 10 years or 200, 000 miles (whichever comes first). So, in most cases you are out of luck for the warranty. Don Willson at VEXEDvolvo.org has put a list of all affected Volvo models as follows:

White label means that your ETM has not been replaced by Volvo

White label means your ETM is original and has not been replaced by Volvo and/or the previous owner

VOLVO / 700 2000
VOLVO / 740 2000
VOLVO / 780 1999
VOLVO / 850 1999-2000
VOLVO / 855 2000
VOLVO / C70 1999-2002
VOLVO / C70 CONVERTIBLE 1999-2001
VOLVO / COTTRELL 1999
VOLVO / S40 2000-2001
VOLVO / S60 1999-2002
VOLVO / S70 1999-2000
VOLVO / S80 1999-2001
VOLVO / S90 1999
VOLVO / V40 2000-2001
VOLVO / V70 1999-2002
VOLVO / V70XC 1999-2001
VOLVO / V90 1999
VOLVO / VOLVO 1999-2001
VOLVO / X70 1999
VOLVO / XC70 2001

All Volvo dealers we contacted were aware of the problem. They all said it could be fixed for around $1,000 after a mandatory two-hour inspection at the dealership at a cost of $89 per hour (Volvo of Chattanooga), $99 per hour (Clayton Volvo of Knoxville) or $105 per hour (Dyer & Dyer Volvo of Chamblee, GA).

However, generally Volvo dealers put the same model ETM part during repair, which causes the same problem after a while. You can purchase the same part manufactured in Canada with already preloaded software and the necessary warranty at: xemodex.com (Thanks for the recommendation by Don Willson at VEXEDvolvo.org)

Apparently, you can get the ETM for your Volvo from any online auto-part store located in Europe even cheaper, but you will need Volvo to load the software on it, which they most probably will not do for you. At least, not for free, judging from their prices above.

You can watch the video bellow of a Volvo with ETM problem and use the following PDF chart to diagnose your ETM. (Chart courtesy of Chris at xemodex.com – Thank you!)

A very, very special “Thank You!” goes also to Rob from VolvoTips.com, who helped us with our engine’s condition remotely.

Chris has shared a video of a Volvo with ETM problem on YouTube. He said that Volvo dealer

“just cleaned the throttle body and upgraded software which reduces the sensitivity of the light but only really masks the problem, I’m living with it as the light only comes on for 5 miles out of every 50-100 now. Should have pushed harder for a replacement but its too late…”
